In the process of gas treatment, petroleum refining and chemical processing, clean gas without liquid mist is very important to the reliability and economic efficiency of the equipment. The unique hnc-tc-qy gas-liquid coalescer is suitable for the separation of water in natural gas. With multi-layer coalescence and separation, the filter material is treated by drainage and oil drainage, and still has a large removal efficiency for the liquid under low pressure difference, which can reduce the liquid content in natural gas to 0.003ppmw Performance specification ● direction of flow in and out: wet natural gas in and out ● replacement pressure drop: 0.8 ~ 1.0bard (12 ~ 14.5psid) @ 70 ℃ (158 ℉) ● temperature rating: min. - 10 ℃ (- 50 ° f) max.70 ℃ (158 ° f) ● outer diameter: 152mm (5.98 in) ● inside diameter: 90mm (3.54 in) ● length: 180-279-559-736-838-1104mm. (7.1-11-14.5-22-29-33-43.5 in) ● filter area: selected according to model and specification ● filter material: it is composed of oil drainage and hydrophobic pleated filter material adhered by specially treated resin ● internal / external metal support: internal / external double-layer stainless steel mesh pipe provides enough axial strength to resist impact force ● end cover: zinc plate application area 1. Protect compressor and turbine 2. Remove lubricating oil, water, compressor wear products, corrosion products and other pollutants in the gas 3. Reduce solution loss of gas purification unit 4. Protect the gas flowmeter to ensure that the flow is correctly indicated 5. Clean fuel gas and protect combustion device 6. Prevent liquid injection hole from blocking in gas overflow 7. Reduce foaming in the contact tower of amine and glycol 8. Protect catalyst, desiccant and adsorbent High efficiency folding coalescence filter element The filter element can effectively remove 99.9% of 0.3um solid particles in the gas, separate oil, water and other droplets from the gas through coalescence, and collect them at the bottom of the filter to prevent the coalesced droplets from entering the downstream gas treatment. In the fields of gas turbine electromechanical plant, natural gas, petrochemical industry, etc., it can be used to remove the solid particles in the steam turbine and compressor Lubricating oil, water or other corrosive substances can reduce the cost of equipment maintenance.
