The u-jm-wq series microporous membrane gas filter is designed and manufactured according to GMP standard. The shell is made of high-quality imported stainless steel (304 / 316L). It has the advantages of high efficiency, energy saving, safety and reliability. It is widely used in the purification of fermentation air, injection air and inert gas. It is specially designed for the purpose of sterilization in the tank gas exchange of pharmaceutical industry and food industry. Product features: Stainless steel 304 / 316L has excellent chemical compatibility; It is designed and manufactured according to GMP requirements, with reasonable structure and excellent processing; Various performance filter elements can be selected to meet different gas requirements; The optimized design of air flow passage can effectively reduce the pressure drop; Compact structure, reduce maintenance space; Special specifications can be designed and customized. Main applications: Matching of various filters in medicine, biology, food, beverage, electronics, chemical industry, machinery, petroleum, polysilicon and other industries;

额定过滤能力（m3/min）	滤芯配置		进出口接管		外形尺寸（mm）					参考重量（Kg）
	芯度	长度	d(mm)	连接形式	A	B	C	D	L
1	1	5〃	DN25	法兰或卡箍		250	370	102	222	5
2		10〃				370	510			6
4		20〃	DN40			610	760			8
6	3	10〃	DN50	法兰	286	400	780	184	444 344	21 15
10		20〃	DN65		296	640	1050		444 344	16 23
15	5		DN80		376	653	1170	234	494 414	36 32
20			DN100		391		1210		494 414	39 35
30	7					663	1260	274	534 454	46 42
40	9		DN125		415	685	1330	306	566 506	60 55
60	12				424	698	1350	356	616 556	69 64
	15					710	1410	406	666 606	89 80
80					434		1440		666 606	93 84
	19		DN150		444				666 606	94 85
100									666 606	94 85
120	29				468	735	1560	506	766 726	139 125
140			DN200		498		1610		766 726	144 130

Technical parameters: Filter medium: air, nitrogen, oxygen, hydrogen, high temperature steam, etc Volume: standard mode holds 12-300 folding membrane filter elements, filter elements Length is 10, 20, 30, 40 (in inches) Filter flow: 1 ~ 1000000nm3 / h, in air Shell material: CS, 304, 304L, 316, 316L, C276, 2205, coating Filtering accuracy: 0.003 μ m ~ 50 μ M Standard: steel pressure vessel, water treatment filter standard, ASME "U" Pressure and temperature: 0 ~ 25.0mpa / 0 ~ 400 ℃ The maximum pressure and temperature are only the grade of the vessel, and the safe operating temperature and pressure will depend on the filter element and sealing ring
